K5F2C-W
- The industry’s first waterproof XLR socket with a waterproof rating of IP65
- 5-pin XLR waterproof female socket with zinc alloy and pearl chrome plated housing and gold plated contacts
- Air-proof treatment at the rear part to prevent water vapor from entering inside the equipment
- D-shape metal shell with industry standard D-type installation dimensions provides installation compatibility
- Install from the front of the panel
- Solve to the fullest degree the fast connection requirements of the DMX lighting industry in outdoor conditions for signal input and output
Contact us
Details
| Product Parameters | |
| Connection type | XLR |
| Gender | Female |
| Electrical parameters | |
| Capacitance between contacts | ≤ 7 pF |
| Contact resistance | ≤ 5 mΩ |
| Dielectric strength | 1500V DC |
| Insulation resistance | > 10 GΩ (initial) |
| Rated current per contact | 7.5 A |
| Rated voltage | < 50 V |
| Mechanical Parameters | |
| Insertion force | ≤ 20 N |
| Withdrawal force | ≤ 20 N |
| Service life | > 1000 mating cycles |
| Chassis shape | D-size |
| Material and Environmental Parameters | |
| Contacts | Cu alloy |
| Contact plating | Au |
| Insert | PA |
| Housing | Zinc alloy |
| Housing plating | Cr |
| Flame-retardant grade | UL 94 HB |
| Protection class | IP65 |
| Temperature range | -30°C ~ +80°C |
| Standards and Certifications | |
| Standards | IEC 61076-2-103 |
| Solderability | IEC 68-2-20 |
Description
K5F2C-W IP65 Waterproof XLR Socket: Professional-Grade Waterproof Connectivity Solution
The K5F2C-W is a premium 5-pin XLR female socket engineered for demanding outdoor applications where protection against moisture and dust is critical. As the industry’s first XLR socket with IP65 waterproof rating, this connector delivers exceptional performance and reliability in challenging environments.
Key Features:
- Superior Waterproofing: IP65-rated protection ensures complete dust-tight design and resistance against water jets from any direction
- Premium Construction: Zinc alloy housing with elegant pearl chrome plating and gold-plated contacts for superior conductivity and corrosion resistance
- Specialized Design: Air-proof treatment at the rear prevents water vapor from entering connected equipment
- Industry-Standard Compatibility: D-shape metal shell with standard D-type installation dimensions ensures seamless installation compatibility
- Front-Panel Installation: Simple and secure mounting from the front of panels
- Ideal for DMX Applications: Perfect for outdoor DMX lighting systems where fast, reliable connections are essential
Technical Specifications:
- Electrical Parameters:
- Rated current: 7.5A per contact
- Rated voltage: <50V
- Contact resistance: ≤5 mΩ
- Insulation resistance: >10 GΩ (initial)
- Dielectric strength: 1500V DC
- Mechanical Durability:
- Service life exceeding 1,000 mating cycles
- Optimal insertion/withdrawal force (≤20 N)
- Material Quality:
- Contacts: Copper alloy with gold plating
- Housing: Zinc alloy with chrome plating
- Insert: PA with UL 94 HB flame-retardant rating
- Operating temperature: -30°C to +80°C
Package Includes:
- K5F2C-W XLR socket
- Waterproof gasket cover
- Back fastener plate
- Mounting screws and nuts
Designed to meet IEC 61076-2-103 standards, the K5F2C-W is the professional choice for outdoor entertainment systems, broadcast applications, and any installation requiring reliable signal connections in demanding environments.
