SO2DF

Description

The SO2DF Optical Fiber Socket is a robust and highly reliable dual-channel connector designed for outdoor use. Crafted for ensuring stable and efficient fiber optical connections, this socket is built to withstand harsh environmental conditions while providing seamless electrical connectivity.

Key Features:

• Durable Construction: Made from high-quality materials including a zinc alloy housing, bronze contacts, and a PA insert, ensuring long-lasting performance.
• Automatic Sealing Shutter: Features a feed-through connection with an automatic sealing shutter, protected by a silicone gasket to safeguard fiber optical connections against dust and dirt.
• Versatile Connectivity: The front end connects with SO2M or standard LC connectors, while the back end accommodates standard LC connectors, facilitating easy installation.
• High Protection Grade: Rated IP65 for outdoor electrical connections, ensuring the socket is well-protected against water and dust ingress.
• Long Service Life: Designed for over 5000 mating cycles, providing reliability and longevity for frequent use.

Technical Specifications:

Connection Type:

• Optical Fiber Feed-through LC

Gender:

• Female

Electrical Parameters:

• Contact Resistance: < 7 mΩ
• Rated Current: 6 A
• Rated Voltage: < 50 V
• Dielectric Strength: 1.5 kV DC
• Insulation Resistance: > 2 GΩ (initial)

Mechanical Parameters:

• Service Life: > 5000 mating cycles
• Insertion Force: ≤ 45 N
• Locking Force: 1000 N
• Chassis Shape: D-size
• Mounting Direction: Front mounting
• Locking Device: Push-button

Material and Environmental Parameters:

• Housing: Zinc alloy
• Contacts: Bronze
• Insert: PA
• Contact Surface: Au
• Split Sleeve: Ceramics
• Temperature Range: -40 °C to +75 °C

Packaging & Accessories:

• Packaging Method:
  • 1 pc per bag (includes 1 pc each of socket and waterproof gasket)
  • 50 pcs per inner carton, 5 inner cartons per master carton (250 pcs per master carton)
• Accessories:
  • No accessories included; optional back fastener plate, screws, and nuts available separately.

The SO2DF Optical Fiber Socket is your ideal solution for reliable and efficient fiber optic connectivity in demanding outdoor environments.
