SAC3MX-67
Product Features
- Lockable three-core male power cable connector with contacts for line, neutral and pre-adapted safetygrounding
- Durable and ruggedly sealed power connector used for electrical connection under outdoor conditions withprotection grade IP67
- The product is designed with 2 sealing protections to enhance reliability
- Match with SAC3FX-67, SAC3FPX-67 or SAC3FPX20-67
- Fast and easy locking system with firm latch lock which does not fall off
- High current capacity rated at 20A/300V AC UL
- UL498 & UL50E Certification No. E356932
Contact us
Details
| Electrical Parameters | |
| Number of Contacts | 2 + PE |
| Rated Current | 20A UL |
| Rated Voltage | 300V AC UL |
| Contact Resistance | ≤ 5 mΩ |
| Dielectric Strength | 4000V DC(1600V/min AC UL) |
| Insulation Resistance | > 1000 MΩ |
| Mechanical Parameters | |
| Service life | > 500 mating cycles |
| Cable Size |
2.5 mm2 |
| Cable OD | 7-11 mm |
| Type of Terminals | Screw type terminals |
| Material and Environmental Parameters | |
| Housing | PA |
| Contacts | Cu alloy |
| Contact surface | Ag |
| Protection degree | IP67 |
| Flame retardant rating | UL94V-0 |
| Temperature range | -30°C ~ +80°C |
| Standards and Certifications | |
| Standards | UL498 | UL50E | IEC61984 | GB/T 34989 |
| Certifications | UL: E356932 | CQC23003410681 |
Description
The SAC3 MX-67 is a robust, IP67-rated waterproof power plug designed for reliable electrical connections in outdoor environments. Engineered by Seetronic, this lockable three-core male connector is equipped with contacts for line, neutral, and pre-adapted safety grounding, ensuring secure and efficient power transmission.
Key Features:
- Locking System: Fast and easy locking system with a firm latch lock that ensures the connector does not fall off during use.
- Durability: Constructed to withstand tough conditions with a rugged, sealed design, making it suitable for outdoor use.
- Compatibility: Designed to match seamlessly with SAC3F X-67, SAC3F PX-67, and SAC3FPX20-67 connectors.
- High Current Capacity: Rated for high current capacity at 20A/300V AC , ensuring it can handle substantial electrical loads.
- Certification Compliance: It meets rigorous safety standards with certifications from UL498, UL50E (Certification No. E356932).
Electrical Specifications:
- Number of Contacts: 2 + PE (Protective Earth)
- Rated Current: 20A (UL)
- Rated Voltage: 250V AC (UL)
- Contact Resistance: ≤ 5 mΩ
- Dielectric Strength: 4000V DC (1600V/min AC UL)
- Insulation Resistance: >1000 mΩ
Mechanical Specifications:
- Service Life: Over 500 mating cycles
- Cable Size: 2.5 mm²
- Cable Outer Diameter (OD): 7-11 mm
- Type of Terminals: Screw type terminals
Material and Environmental Specifications:
- Housing Material: PA (Polyamide)
- Contacts Material: Copper alloy with Ag (Silver) surface
- Protection Degree: IP67, providing excellent water and dust protection
- Flame Retardant Rating: UL94-V0
- Temperature Range: -30°C to +80°C
Standards and Certifications:
- Standards: UL498, UL50E, IEC61984, GB/T 34989
- Certifications: UL (No.E356932), CQC (No. 23003410681)
Packaging:
- Individual Packaging: 1 piece per bag, including inner core, housing, strain relief, bushing, and waterproof rubber ring
- Bulk Packaging: 50 pieces per inner carton, 5 inner cartons per master carton (total 250 pieces per master carton)
Assembly Instructions:
- Thread the cable through the bushing and strain relief.
- Strip the cable to the specified length.
- Insert the cable conductors into the terminal of the inner core and secure with a torque of 0.7 Nm.
- Push the inner core component into the housing with the strain relief, ensuring the ribs align correctly.
- Tighten the boot in a clockwise direction with a torque of 2.0 Nm.
Note: The product includes two sizes of waterproof rubber rings to accommodate different cable diameters (7-9mm and 9-11mm).
The SAC3 MX-67 power plug offers exceptional durability, high current capacity, and reliable performance, making it an ideal choice for outdoor electrical connections.
